Transmitter 220 x 110 x 90mm approximately 860g (without batteries)
Three-level indicator
Receiver 290 x 230 x 70mm about 2200g (without cable)
AC 12/24/36/48/110/220 / 380V, DC 12/24 / 48V, (output passive switch signal)
Operating distance: 100M-500M
Protection: IP65 waterproof and dustproof
Center Band: VHF315MHz, UHF433MHz
Security: Hamming code, watchdog group 4.3 billion unique identifier (32 yuan)
Nylon glass fiber to prevent damage and fading caused by the strong collision: shell material.
Maintenance: 100% complete hardware / software completely consistent, easy to maintain and cost savings
Power consumption: DC6V, recommend choose 2500ma or more rechargeable batteries, without any performance impact
Function Setting: You can set a variety of key functions (Widows9x / XP / Vista / 7/8/10) via the computer software to meet various technical requirements
F24-60 | F24-60+
- Commonalities:
- Overall size,Complete replacement
- Voltage-loss protection in accordance with four level regulatory
- Paragraph 1-5 wireless remote control
- Cross, universal-optional, flexible 1 to 5 sets no extra costs
- Features: double rocker 8 + 4 toggle switches + 5-speed button + start + 1 stop 1 + 1 turn the key
- Difference:
- The new technology, automatic frequency hopping, new rocker
Description
WIRE COLOR F24-60 | F24-60+
WIRE COLOR F24-60 | F24-60+
